igubal JEM SP – the versatile endurance runner

The JEM-SP bearing insert manufactured by injection moulding can be used in pillow block bearings and flange bearings. It consists of the high-performance polymer iglidur J, which is characterized by particularly low wear, a long service life and low moisture absorption.

Thanks to the embedded solid lubricant, no additional lubrication is required, which makes operation in dirty environments particularly advantageous. Our bearing inserts are easy to install and offer a cost-effective and lightweight alternative to a conventional metallic ball bearing.

Housing compatibility

In our shop you will also find flange bearings and pillow block bearings with plastic housings, which have a positive effect on the overall weight of your plant.

As a PTFE-free alternative, we also offer our injection-molded bearing inserts made of iglidur J3: J3EM-SP

igubal J bearing insert

• Temperature range [°C]: -50 bis +90, short-term +120
• Shaft diameter: 17 mm - 24 mm
• Housing sizes: P/F/FL 203 - 210, PP/PFL 204 - 208
• Advantages: Maintenance-free, lubrication-free, durable, insensitive to dust and dirt, vibration-damping, good chemical resistance, low moisture absorption, good wear resistance, resistant up to a radiation intensity of 3 - 10² Gy.
• Dimensional series: In accordance with DIN 626-1
• Application environment: High speeds, high wear resistance under low to medium pressure loads, low wear with a large number of different shafts, low coefficients of friction in dry running, best behaviour with soft shafts
