drylin® E 免上油線性滑台系統特殊步進馬達,帶接頭、編碼器和防濺罩,NEMA 23

  • Installation size: NEMA23 / flange dimension 56mm
  • Protection class: IP65
  • Holding torque: 1.70 Nm
  • Nominal current: 3.00 A
  • Motor connections: Metric M12 connectors
  • Shaft seal prevents water ingress
產品描述
The IP65 (splash water) stepper motors are ideally suited for applications in humid environments.

Applications in the food, outdoor or spray water sector can now also be operated by motor with the proven drylin® linear systems. The IP65 stepper motor can be cleaned with water.

Stepper motors from igus® are a good supplement to drylin® linear axes. They are characterised by their cost-effectiveness, their precision and easy control. They work reliably under the most varied environmental conditions (depending on the selected class of protection IP). The igus® stepper motors can be connected to the most common motor controls using standardised electrical connection.

The connector interface provides a high IP65 protection level (IP: International Protection). The higher the IP rating, the better the motor is protected from the ingress of dirt and water.

The encoder sends signals from the motor to the motor control. The encoder verifies that the required linear motion has occurred precisely as required. Encoder = increased machine accuracy.
認證和標準
CE
EMV 準則
技術資料
下載
