立即改變: 易格斯 igus® 運動工程塑膠 motion plastics® – 讓產品使用壽命更長!

耐腐蝕, 堅固及可靠

如今,igus®塑鋼拖鏈已在成千上萬的應用中被使用–它們可引導和保護石油平台、鋼鐵廠和其他重型機械中的電線電纜和空油壓管。 塑鋼拖鏈採模組化設計,因此易於安裝。它們對不傷害電線和空油壓管線,非常適合用於大型機械及重工業的供電系統使用。 我們的塑鋼拖鏈可承受溫度高達+850°C的熱切銷屑。

許多論點都主張在移動應用中使用高性能塑膠的拖鏈,特別是在重工業的領域中。


堅固且靈活

最高可耐850 °C高溫切削屑

負載可達 600 kg/m

90,000種型號常備庫存

100% 耐腐蝕

能夠快速安裝

易於裝填電纜及管線

重量輕

安靜運行

減震

免保養

100% 免上油

可應用於圓周運動(環形移動)

不含集電滑環的捲線裝置

降低 80% 的組裝成本

保固 36 個月的電線電纜

減少75%驅動力

可線上計算產品使用壽命

可下載 CAD 檔案

經濟實惠

特殊組裝需求

全球服務

24h快速出貨服務

重工業的應用實例

Bucket wheel excavator

Energy chain system e-loop is used in the bucket wheel excavator of Holcim for cement production.

Energy chain in open-air storage facility for alumina production

Design and installation of a roller energy chain for outdoor use on a bauxite stockpile - an environment with extremely harsh ambient conditions.

Ejection belts

The conveyor belt conveys highly flammable sulphur and transports it to its destination in the harbour area.

Assembly robot

This robot lifts heavy work pieces weighing up to 1.7 tons.

Tunnel building crane

Tunnel construction is generally space constrained, thus requiring compact components.

Coal transport system

The motors in this system need a large number of cables.

Working platform

This new design permits a variety of multiple tunnel construction processing steps to be performed by one machine.

Casting implements for car rims

Automotive wheels are manufactured here using the gravity die casting process.

Zinc electrolysis, bathing halls

The sulfur fumes generated by the electrolysis are highly corrosive and corrode the customer's system. igus® products withstand these extreme conditions.

Rocket launch site

The igus products used are designed for moving applications in such a way that they have a long service life and are absolutely reliable.

Heavy load transporter

Rugged energy chains are technically and economically the first choice in the construction of an extendable heavy load transporter.

最長行程的塑膠拖鏈

新加坡港迄今為止最長的行程拖鏈超過了 615 m。

Taconite mine

The next long distance with a plastic chain: 550 m.

Tile factories

Extreme stressing from tile dus in the building material industry.

Road construction

An asphalt finisher applies hot and cold bitumen mixtures. The e-chain® supplies the front area of the vehicle and is exposed to extreme dirt.

Heavy fillings

e-chains® for heavy-duty uses: Guiding of the supply cables of a quenching chamber, which moves toward the linked vacuum ovens.

Power plants

Safe function despite extreme dirt accumulation: Parallel facility in the waste-to-energy plant

Waste incineration plant

Safe application of e-chains® in waste incineration plant

Tunnel construction

Tunnel boring in defined sections with the assistance of an igus® e-chain system®, which guides the essential hose cables section by section.

Steel mills

Temperatures up to 1200°C or lashing blaze from the oven pose high demands on the plant.

Waste incineration plant

Application of e-chains® in waste incineration plants: Strong dirt with high metal content and 300,000 t waste every year.

Thermal application

igus® roller chain in power plant application: Strong dust, application of the chains in trolley and crane, the crane drive arranged in the opposite direction.

Coal-fired power plant

Operation in severe dust. The energy chains are employed in trolley and crane, the crane drive arranged in the opposite direction.

Offshore industry

High pressure hydraulic hoses + power cables. Extreme weather environment but this chain delivers and delivers.

Coal-fired power plant

e-chain system® for a coal unloader. Operating since three years without any problem.

Ship unloading crane

Application of e-chain® systems in ship unloader

Offshore industry

Tube handling plant provides an igus® plastic e-chain®. e-chain® ensures high stability and reliability in pipehandling.

Steel works

Extremely difficult conditions: Dirt and dust, heavy filling, long travel and high temperatures. The system functions since 2003.

Mining industry

The e-chain® is located in the area of the rotating assembly in a bucket-wheel excavator.

Lignite quarrying

The wagon makes a 180° turn and empties into the coal bunker. The energy chain secures the energy supply of the rotating device.

Composting plant

Heat, abrasive dirt, high atmospheric moisture: These are only some of the ambient conditions in a composting plant.

Sewage treatment plant

Energy chain system instead of cable drum - Smooth operation at the sewage treatment plant since 2000

混凝土切管機

在重載型應用中的混凝土切割機,免維修期科長達三年

Ship unloader

441 m travel: Reduction of tensile forces by about 75%.

Sewage treatment plant

The used igus® products prove themselves till today and drastically reduce the maintenance input.

Sewage treatment plant

The existing system with a motor cable drum proved to be not resistant enough in the difficult outdoor environmental conditions, and was replaced by a flizz® system.

Piling and drilling rigs

The driven boring machine produces extremevibrations and heavy soiling duringthe work process.

Dismantling tool

Flexible chainflex® CF9 control cables and various hoses in zig-zag application.

Maintenance-free operation for 8 years

The energy chain employed in 2000 runs smoothly.

Indoor and outdoor cranes

Outdoor cranes must withstand harsh weather conditions. Indoor cranes also work under alternating moisture influences with simultaneous extremely high temperatures.

Deep drilling system TBA

Energy chains in automated deep drilling rig.

更多嚴苛的應用範例

挪威 Aker Kværner Maritime Hydraulics AS的垂直應用範例。
為半沉浸式平台West Edrill 安裝。

德國 拆除卡爾斯魯爾(Karlsruhe)的研究反應爐。 用之字型(zigzag)拖鏈來拆除核電站。

捷克 Lhoist a.s. 石灰工程中的模組化金屬設計。

捷克 就在煤炭輸送機上的全閉式拖鏈系統 E-ChainSystem®。

捷克 Porici CEZ a.s.公司 卸煤運輸的電力供應。

捷克 在電廠中內部地堡的通風設備機器。

澳洲的Midland Bricks是全球最大的磚塊製造商!三年以來,三條拖鏈全天候運行,目前看起來就像第一天使用的那樣。

馬鞍山鋼鐵廠:高溫,重負荷,粉塵量大,溫度高。

德國鋼鐵廠 voestalpine Stahl Donawitz:在要銑削的鋼軌結垢期間會積聚大量灰塵。

斯洛伐克的鋁廠。 9年的使用期間,無任何故障。 行程 62 m, 速度 0.3 m/s.

捷克 在石灰工程的通風設備機器。

德國 自1998年以來,位於路德維希港的巴斯夫(化肥生產基地),塑鋼拖鏈 e-chain®型號:4040.32.250.0

奧地利,尼克拉斯多夫,ABV,區域供熱設備廠(蒸氣設備廠)

印度的RTG設備,行程:22 m,塑鋼拖鏈®:5050.30.550.0,客戶:Kalmar,用於ATM

石膏粉塵

帶有igus®拖鏈系統®的岸邊起重機。 最大行程可達 800 m。

挪威:在洗車場中使用耐彎曲電線電纜chainflex®加拖鏈e-chain®的組合。每天與街道的灰塵和泥土接觸。 耐彎曲電線電纜 chainflex® 的性能非常好。

中國的沙鋼鋼鐵廠 高溫,高速,高粉塵。

捷克 CEZ a.s. 卸煤機能的電力供應的模組化設計。

散裝貨物存儲系統的長行程應用

在巴拿馬的起重機製造商Noell。 應用實例: RTG天車; 行程: 19.5 m; 最高可達 60 m/min.

捷克 船廠Kresice-Loubi;貨船加油站。

肥料處理廠

中國南京的眉山鋼鐵廠。 天車,高粉塵,高速

測試... 測試 ... 再測試

igus® 測試實驗室

igus®在室內2,750平方米的測試區域內擁有業內最大的測試實驗室,專門為能量傳輸保護拖鏈,耐彎曲電纜,工程塑膠軸承以及線性滑軌,魚眼軸承和線性滑台提供測試設置,免上油螺桿,圓棒材,活塞環等
