drylin® 線性滑台 EGW-20，帶齒輪齒條驅動
| 產品型號 | 最大限度。行程長度 [mm] | 重量 [kg] | 每 100 mm [kg] 的額外重量 | 傳動 [mm/轉] | 牙型規格 | 齒條 材質 |
|---|---|---|---|---|---|---|
| EGW-20120 | 10,000 | 7.8 | 0.88 | 157 | 模組1 | iglidur® RN202 |
| 產品型號 | A [mm] | Al [mm] | H [mm] | E2 [mm] | E3 [mm] | E4 [mm] | C4 [mm] | f [mm] | g2 |
|---|---|---|---|---|---|---|---|---|---|
| EGW-20120 | 172 | 250 | 102 | 100 | 180 | 40 | 240 | 2 | M8 |
| 產品型號 | d2 h7 | I [mm] | D [mm] | K DIN 912 - M6 | as [mm] | lu [mm] | ha [mm] | Al2 [mm] | |
|---|---|---|---|---|---|---|---|---|---|
| EGW-20120 | 14 | 417 | 20 | M8 | 120 | 40 | 59 | 150 |
